Enclosure Heater 150W 110-265V | RRE PTC heater

AED 75.00 Incl. VAT

Technical Specifications

Part Number: RRH150W
Operating voltage: 120-240 AC/DC *(DC voltage limit :min 110V max,265V)
Rated Power (W): 150
Rated Current (A): 9
Heating element: PTC resistor, self-regulating and temperature-limiting
Heater body: Extruded aluminum profile, anodized
Connection: 3 pressure clamps for stranded wire 0-5-1.5mm²
Mounting: Clip for 35mm DIN rail, EN 50022
Operating /Storage temperature: -45 to +70°C(-49 to +158°F)

SKU: RRH150W

Description

RRE Semiconductor Heater 150W (Enclosure heater)

  • Dynamic heating
  • Wide voltage range
  • Energy efficient
  • Clip fixing
  • Quick installation

These heaters (with terminal block) are used in enclosures where damage from condensation must be prevented, or where the temperature may not fall below a minimum value. The aluminum profile heater body design has a chimney effect and distributes the heat evenly the heaters are designed for permanent operation .pressure clamp connectors save time and simplify installation.

Additional information

Brand

Product Type

Enclosure Climate Control

Switchgear Category

Ventilation Systems

Power Rating

150W
